| Rated load (Q) | 2000kg |
| Lifting height (h3) | 205mm |
| Load center distance (c) | 600mm |
| Fork size (l/e/s) | 1150/170/60mm |
| Wheelbase(y) | 1150mm |
| Braking method | electromagnetic |
| Vehicle weight (including battery) | 370kg |
| Tire type, drive side/load side | Polyurethane |
| Tire size, load side | φ80*70mm |
| Tire size, drive side | φ210*75mm |
| Wheelbase, load side (b4) | 520mm |
| Navigator bracket reference height (h2) | 1890mm |
| Vehicle length (including safety edge) (L1) | 1645mm |
| Vehicle width (including safety edge) (b1) | 850mm |
| Fork outer distance (b6) | 680mm |
| Minimum height of fork surface from ground (h6) | 85mm |
| Minimum ground clearance (when fork is raised) (m1) | 40mm |
| Turning radius (including safety edge) (Wa) | 1360mm |
| Travel speed, full/empty | 1.0/1.5 m/s |
| Lifting speed, full/empty | 40/50 mm/s |
| Lowering speed, full/empty | 50/40 mm/s |
| Maximum climbing ability, full/no load (S2-5min) (tanθ) | 3%/5% |
| Driving motor power (servo motor) | 1kw |
| Lifting motor power, (S3-10%) (DC compound excitation) | 0.8kw |
| Steering motor (servo motor) | 0.4kw |
| Lithium battery, voltage/rated capacity | 48V/50Ah |
| Charging method | Automatic/Manual |
| Right angle stacking channel width (pallet 1000×1200) 1200 across fork direction C500 (Ast) | 1975+200mm(Safety distance) |
| Right angle stacking channel width (pallet 1000×1200) 1200 along the fork direction C600 (Ast) | 1960+200mm(Safety distance) |
| Rated load (Q) | 2000kg |
| Lifting height (h3) | 205mm |
| Load center distance (c) | 600mm |
| Fork size (l/e/s) | 1150/170/60mm |
| Wheelbase(y) | 1150mm |
| Braking method | electromagnetic |
| Vehicle weight (including battery) | 370kg |
| Tire type, drive side/load side | Polyurethane |
| Tire size, load side | φ80*70mm |
| Tire size, drive side | φ210*75mm |
| Wheelbase, load side (b4) | 520mm |
| Navigator bracket reference height (h2) | 1890mm |
| Vehicle length (including safety edge) (L1) | 1645mm |
| Vehicle width (including safety edge) (b1) | 850mm |
| Fork outer distance (b6) | 680mm |
| Minimum height of fork surface from ground (h6) | 85mm |
| Minimum ground clearance (when fork is raised) (m1) | 40mm |
| Turning radius (including safety edge) (Wa) | 1360mm |
| Travel speed, full/empty | 1.0/1.5 m/s |
| Lifting speed, full/empty | 40/50 mm/s |
| Lowering speed, full/empty | 50/40 mm/s |
| Maximum climbing ability, full/no load (S2-5min) (tanθ) | 3%/5% |
| Driving motor power (servo motor) | 1kw |
| Lifting motor power, (S3-10%) (DC compound excitation) | 0.8kw |
| Steering motor (servo motor) | 0.4kw |
| Lithium battery, voltage/rated capacity | 48V/50Ah |
| Charging method | Automatic/Manual |
| Right angle stacking channel width (pallet 1000×1200) 1200 across fork direction C500 (Ast) | 1975+200mm(Safety distance) |
| Right angle stacking channel width (pallet 1000×1200) 1200 along the fork direction C600 (Ast) | 1960+200mm(Safety distance) |
